Maximilian Ackermann, Steven J. Mentzer, Martin Kolb, Danny Jonigk
European Respiratory Journal 2020 56: 2003147; DOI: 10.1183/13993003.03147-2020
Inflammation and intussusceptive angiogenesis in COVID-19 https://bit.ly/30lLh8K
The human body contains 60 000 miles of blood vessels, including at least 19 billion capillaries, so that under physiological conditions cells are located no further than 100–200 μm from the nearest capillary. In those, endothelial cells and pericytes seem to play a pivotal role in coronavirus disease 2019 (COVID-19) by binding severe acute respiratory syndrome coronavirus 2 (SARS-CoV-2) to the angiotensin-converting enzyme 2 (ACE2). In the lung, the transmembrane ACE2 receptor is predominantly expressed in endothelial cells, perivascular pericytes and type 2 cells.
We recently showed that SARS-CoV-2 infection leads to angiocentric inflammation in COVID-19-induced respiratory failure, with a greater number of ACE2-positive endothelial cells compared to uninfected controls or to post mortem lung tissue from patients who succumbed to influenza A-related acute respiratory distress syndrome (ARDS). Although the detection of SARS-CoV-2 in post mortem tissue by transmission electron microscopy is a challenging task, replicated virus-like particles were observed enveloped in endothelial cells and lymphatic cells, and also in type 2 and 1 pneumocytes. Increasing clinical evidence shows that endothelial dysfunction is a common denominator after SARS-CoV-2 infection in the multi-organ complexity and severity of COVID-19. COVID-19-related endothelial dysfunction is characterised by acute vascular inflammation and perivascular T-cell recruitment leading to disruption of the alveolar–capillary barrier and increased permeability. The endothelial cells surrounded by T-lymphocytes show features of strong activation referred to as “endothelialitis”, a process typically seen during rejection of solid organ transplants. The infection of endothelial cells by SARS-CoV-2 results in swelling and disruption of the endothelial cell barriers, an anomalous microvascular architecture, and an endothelial dysfunction. These vascular injuries are accompanied by thrombosis, vasoconstriction and distinct intussusceptive angiogenesis, a unique rapid process of blood vessel neoformation by splitting a vessel in two lumens by an incorporation of circulating angiogenic cells (figure 1a) . In the pulmonary vasculature from autopsies of COVID-19 patients, we observed a distinct occurrence of intussusceptive angiogenesis not only in early SARS-CoV-2 infected lungs, but also in lung tissue with an infection lasting more than 20 days. Beyond these findings in COVID-19 post mortem lung tissue, we revealed distinctive features of compensatory angiogenesis by intussusception in many other organs such as heart, liver, kidney, brain and lymphoreticular organs in patients who succumbed to COVID-19. The chaotic vessel regulation of focally vasoconstricted and progressively dilated vessel segments results in severe disturbances of physiological laminar flow. Two major forms of thrombi have been reported so far in COVID-19 patients. Pulmonary embolism in larger pulmonary vessels probably based on deep vein thrombosis were seen in a minority of COVID-19 patients, whereas the vast majority demonstrated platelet aggregates obstructing the microvasculature and peripheral vascularity caused by fibrin strands, activated platelets, deformed neutrophils and neutrophil extracellular traps. Viral-associated thrombotic microangiopathies have been described in numerous inflammatory cardiorespiratory diseases (e.g. influenza or myocarditis). We compared post mortem lung tissues from patients who died from COVID-19 with severe ARDS and diffuse alveolar damage due to influenza A (H1N1) infection. Thereby, we found nine times more microthrombi in COVID-19 lungs compared to influenza A (H1N1) lungs. The microangiopathy observed in COVID-19 patients, specifically, the vasoconstriction and clotting in smaller blood vessels, results in hypoxia, shunting and an increase of pulmonary vascular resistance. Interestingly, COVID-19 does not show characteristics of a “typical” ARDS. The discrepancy between a general well-preserved lung mechanics and the severity of hypoxaemia could be explained by a decreased capacity of vascular tone in venules and the capillary plexus. Our molecular data on COVID-19 lung tissue gave evidence of a significant upregulation of vasoconstrictive mediators such as prostaglandins (phospholipase A, leukotrienes), as well as an increase of nitric oxide synthase (NOS). Nitric oxide is produced in endothelial cells by the enzyme endothelial nitric oxide synthase (eNOS) or in monocytes and macrophages by inducible nitric oxide synthase (iNOS). The rheologic properties of blood flow (laminar versus turbulent) and vessel morphology determine the shear stress on the vascular wall. In general, high shear stress, as observed in physiological laminar flow, is considered angioprotective, promoting endothelial cell survival, vasodilation and anticoagulation. Low shear stress, on the other hand, results in the secretion of vasoconstrictors, platelet aggregation, coagulation and pathological reshaping of microvascular architecture. The pathological consequences of these blood flow dynamics have been described in many diseases, such as atherosclerosis, inflammatory diseases and malignancies. Our own haemodynamic studies on inflammatory-related changes of the blood flow revealed heterogeneity in flow patterns, with dispersed flow velocities, occluded vessel segments and platelet aggregates associated with upregulation of thrombotic agonists.
a) Schematic of pulmonary endothelialitis, thrombosis, and intussusceptive angiogenesis in coronavirus disease 2019 (COVID-19). SARS-CoV-2: severe acute respiratory syndrome coronavirus 2. b) Intussusceptive angiogenesis is a morphogenetic process which rapidly expands the vascular plexus. c) Transmission electron micrograph of lung tissue of a deceased COVID-19 patient highlights the formation of an intussusceptive pillar (red arrowheads) which spans the lumen of the vascular walls. rbc: red blood cells. d) A disrupted vascularity with distorted vessels and intussusceptive pillars (blue arrowheads) is observed in COVID-19 lungs, as depicted as scanning electron micrograph of microvascular corrosion casts of COVID-19 autopsies.
The structural adaption of the microvascular architecture, the transmigration of lymphocytes and the “cytokine storm” observed in COVID-19 patients is a response to SARS-CoV-2-induced cellular damage. Many cytokines appear to be involved in enhancing lymphocyte recruitment. Tumour necrosis factor α (TNFα) is known to increase the adhesion of lymphocytes by activating the SDF-1/CXCR4 pathways. The T-lymphocyte/ endothelial interaction likely contributes to the prolonged interstitial inflammation in COVID-19. Activated T-cells attracted by chemotactic chemokines (e.g. CCL17, CCL8 or CCR1) preferentially adhere to activated endothelial cells. Despite an increase in inflammatory blood flow and increased wall shear stress, transendothelial lymphocyte recruitment can occur in selected capillary beds (liver and lung), post-capillary venules (most parenchymal organs), and even specialised vascular segments that acquire structural modifications that reduce flow velocity and wall shear stress. Therefore, the structure of the microcirculation is continuously adapting to metabolic demands and immunosurveillance. The close association of inflammation and angiogenesis represents a pivotal pillar in perpetuating inflammatory processes during wound healing and infections such as COVID-19. Inflamed human endothelial cells and pericytes express high levels of toll-like receptors (TLRs) which are recognised together with their intracellular adaptor protein MyD88 as sentinels of the innate immune system. SARS-CoV and other coronaviruses may be recognised by TLRs and MyD88. Stimulation of endothelial TLRs and MyD88 results in a release of cytokines (e.g. interferon γ, TNFα, interleukin 1α, granulocyte colony-stimulating factor), chemokines, leukocyte adhesion molecules (e.g. E-selectin, intercellular adhesion molecule 1, vascular cell adhesion protein 1), procoagulation mediators (e.g. fibrin, plasminogen activator inhibitor, von Willebrand factor), and proangiogenic factors (e.g. vascular endothelial growth factor (VEGF), NOS or CD14 monocytes).
“Intussusceptive” (non-sprouting) angiogenesis is a well-characterised morphogenetic process in cancer, inflammatory diseases and tissue regeneration. Distinct from intussusceptive angiogenesis, sprouting angiogenesis is characterised by sprouts composed of endothelial cells. The endothelial sprouts typically grow toward an angiogenic stimulus (such as VEGF-A) and add vessels to tissues devoid of blood vessels. Intussusceptive angiogenesis is a rapid process of intravascular septation that produces two lumens from a single vessel within minutes. The process appears to recruit bone-marrow derived mononuclear cells, expanding and adapting capillary plexuses without requiring active proliferation of endothelial cells (figure 1b). The newly formed “intussusceptive pillars” (figure 1c) are then permeated by pericytes and myofibroblasts providing mechanical stabilisation of the transcapillary pillar core. We previously showed that this formation of intussusceptive pillars is primarily located in dilated vascular segments with low blood flow velocity and reduced wall shear stress. Recently, CXCL12/CXCR4 signalling has been identified as an important molecular regulator of intussusceptive angiogenesis and hypoxia: the positive feedback loop between vascular shear stress, CXCL12 (SDF1) expression, hypoxia and the release of eNOS has been identified as an adaptation of the vascular system to maintain blood flow responsive to the demands of prolonged inflammation. Therefore, the pronounced release of eNOS cascade is a pivotal physiological process to maintain blood flow into tissues with occluded vessels and to initiate tissue repair by expanding the vascular architecture by intussusceptive angiogenesis. In our own studies, we observed abundant intussusceptive angiogenesis in the disrupted pulmonary vascular architecture of patients who died of COVID-19 (figure 1c and d), stated in numbers nearly three times higher than in influenza A (H1N1) lungs. Furthermore, the expression of CXCL12 and CXCR4 was highly upregulated in these COVID-19 lungs and was associated with dense T-cell infiltration. These findings are consistent with inflammation-induced angiogenesis observed in other conditions, such as colitis and malignant tumours.
In a recent morphomolecular study published in the European Respiratory Journal, we demonstrated the presence and impact of microvascular alterations in fibrotic interstitial lung diseases. We observed a higher frequency of intussusceptive features in the injury patterns of nonspecific interstitial pneumonia and alveolar fibroelastosis fibrotic lungs, whereas usual interstitial pneumonia lungs revealed compensatory angiogenesis predominantly by sprout formation. In addition, intussusceptive angiogenesis was observed in chronic pulmonary vascular diseases with variable degree of thrombosis, such as chronic thromboembolic pulmonary hypertension ], pulmonary capillary haemangiomatosis, and pulmonary veno-occlusive disease (table 1). Although the pathological mechanisms underlying fibrotic remodelling in pulmonary thromboembolic occlusions are poorly understood, thrombofibrosis and endothelial–mesenchymal transition seem to be promoted by hypoxia-induced activation of endothelial cells, intussusceptive angiogenesis, activation of mesenchymal cells and immune cells. There is a compelling evidence that at least the progress and severity of progressive interstitial lung disease may be influenced by coagulation and fibrinolytic capacities and vascular permeability, although the therapeutic use of orally administered anticoagulants has been critically evaluated in idiopathic pulmonary fibrosis patients. Especially in the light of inestimable long-term complications in COVID-19, further experimental and observational studies should investigate the contribution and the interplay between the overwhelming angiocentric T-cell inflammation, thrombotic microangiopathy and the compensatory flow-regulated intussusceptive angiogenesis in the increased morbidity and mortality of COVID-19.
Histological features of lung diseases relevant to intussusceptive angiogenesis
Conflict of interest: M. Ackermann has nothing to disclose.
Conflict of interest: S.J. Mentzer has nothing to disclose.
Conflict of interest: M. Kolb reports grants and personal fees from Roche, Boehringer Ingelheim and Prometic, grants from GSK, Respivert, Alkermes, Pharmaxis and Canadian Institute for Health Research, personal fees from Genoa, Indalo, Third Pole and Pieris, outside the submitted work.
Conflict of interest: D. Jonigk has nothing to disclose.
